V7 High Vacuum Portable Medical Suction Unit

The V7 High Vacuum Portable Medical Suction Unit is a portable suction device designed for healthcare facilities, home healthcare, ambulances, patient transport, and emergency situations. Manufactured by Hersill, the V7 range is intended for suction applications in surgery, gynaecology, and ear, nose, and throat (ENT) care.

The V7 features a long-life, medical-grade piston pump that operates without oil and is designed to be maintenance-free. Its precise vacuum control knob allows healthcare professionals to adjust suction, while the integrated vacuum gauge provides readings from 0 to 100 kPa (0–760 mmHg).

Designed for portability and practical operation, the unit features an ergonomic ABS housing and an anchorage system tested to withstand 10 g. Depending on the model, it may include a rechargeable battery with LED charge indicators, allowing operation away from a fixed power source.

The V7 also incorporates a collection jar with an overflow safety valve and a hydrophobic PTFE bacterial filter. Its compact construction and model-dependent weight of approximately 2.2–4.5 kg make it suitable for use across different healthcare environments.

Key Features

• High-Vacuum Suction: Designed for medical suction applications in clinical and emergency settings.

• Medical-Grade Piston Pump: Long-life pump designed for oil-free, maintenance-free operation.

• Adjustable Vacuum Control: Precise control knob for regulating the vacuum level.

• Integrated Vacuum Gauge: Measurement range of 0–100 kPa (0–760 mmHg).

• Ergonomic ABS Housing: Durable, portable casing designed for convenient handling.

• 10 g Anchorage System: Anchorage system tested to 10 g, supporting appropriate transport applications.

• Visual Status Indicators: Indicators for power, flashing status, vacuum level, vacuum indication, and battery status, depending on model.

• Low Noise Operation: Maximum noise level specified as 49 ± 1.5 dB, depending on model.

• Optional Battery Operation: Long-duration battery autonomy is available on selected models.

• Collection Jar with Overflow Protection: Polycarbonate or polysulfone collection containers with an overflow safety valve.

• Hydrophobic PTFE Filter: Designed to provide bacterial and particle retention.

• Disposable Canister Compatibility: Optional holders are available for compatible disposable canister systems.

• Moisture-Protected Power Switch: ON/OFF switch designed with moisture protection.
