IKEDA Digital Colposcope Camera with 20X Optical Magnification

The IKEDA Digital Colposcope Camera is designed for detailed visual examination during gynecological procedures. It features a 1/2.8-inch Sony CCD camera with approximately 2.1 million pixels and supports 1920 × 1080 image resolution for clear video output.

The colposcope provides 20X optical magnification and 12X digital magnification, with automatic or manual focusing options. Its imported high-brightness white LED light source provides illumination during examination, while automatic and manual white balance and electronic color filtering support image adjustment.

The system also includes a 3.5-inch LCD screen, DVI output, CVBS/Y/C video output, foot-switch control, wired remote control, and image-freeze functionality. The working/object distance is 30–50 cm, making it suitable for clinical examination environments.

Key Specifications

• Brand: IKEDA
• Camera: 1/2.8" Sony CCD
• Total Pixels: 2.1 million
• Image Resolution: 1920 × 1080
• Scanning: Progressive scanning
• Frame Rate: 30p at 1920 × 1080
• Light Source: High-brightness white LED
• SNR: More than 50 dB
• Magnification: 20X optical, 12X digital
• Object Distance: 30–50 cm
• Focus: Automatic, manual, or software interface
• White Balance: Automatic and manual
• Video Output: CVBS 1.0 Vp-p (75), Y/C
• Horizontal Resolution: More than 1080 lines
• LCD Screen: 3.5-inch
• Image Freeze: Foot button, software, and wired remote control
