VSM-09A Handheld Patient Monitor with SpO2 and Pulse Rate Monitoring

The VSM-09A Handheld Patient Monitor is a compact medical monitoring device designed for vital-sign assessment in hospitals, clinics and point-of-care settings. Its lightweight handheld design and 3.5-inch color LCD display allow healthcare professionals to view patient measurements conveniently.

The standard configuration supports SpO₂ (blood oxygen saturation) and pulse rate monitoring, while optional configurations include non-invasive blood pressure (NIBP) and temperature measurement. The device offers manual, automatic and continuous NIBP measurement modes when the NIBP option is installed.

Powered by a rechargeable 3.7V, 4000mAh lithium-ion battery, the monitor provides up to 15 hours of operation under specified conditions. A USB communication interface supports data communication, and the compact design makes the device convenient for clinical and point-of-care use.

Key Features:

• SpO₂ Monitoring: Measures oxygen saturation within the specified range of 0–100%.

• Pulse Rate Monitoring: Measures pulse rates from 20 to 254 bpm.

• Optional NIBP Measurement: Supports manual, automatic and continuous measurement modes in equipped versions.

• Optional Temperature Measurement: Supports temperature readings from 0°C to 50°C.

• 3.5-Inch Color LCD: 480 × 320 pixel display for viewing measurements.

• Rechargeable Battery: 3.7V, 4000mAh lithium-ion battery.

• Battery Operation: Up to 15 hours, depending on configuration and operating conditions.

• USB Interface: Supports communication with compatible systems.

• Compact Design: Measures 175 × 85 × 32 mm.

• Multiple Patient Groups: Designed for neonatal, pediatric and adult patients, subject to compatible accessories and configuration.

Technical Specifications:

• SpO₂ range: 0–100%

• SpO₂ accuracy: ±2% for the specified 70–100% range

• Pulse rate range: 20–254 bpm

• Temperature range: 0–50°C

• Temperature accuracy: ±0.2°C

• Display resolution: 480 × 320 pixels

• Dimensions: 175 × 85 × 32 mm

• Weight: 280 g (SpO₂ version) / 370 g (SpO₂ + NIBP + temperature version)

• Battery charging time: Approximately 8 hours
