TD4 Tabletop Low-Speed Laboratory Centrifuge with Digital LCD Display

The TD4 Tabletop Low-Speed Centrifuge is a laboratory centrifuge designed for sample separation in medical and laboratory environments. It features microcomputer control, a digital LCD screen and a DC brushless motor designed for low-noise operation and stable speed performance.

The TD4 supports a maximum speed of 4,000 rpm and a maximum relative centrifugal force (RCF) of 2,500 × g, depending on the rotor configuration. Its compact tabletop design makes it suitable for laboratories that require controlled centrifugation for routine sample processing.

Key Features:

• Maximum speed of 4,000 rpm

• Maximum relative centrifugal force of 2,500 × g

• Digital LCD screen for convenient operation

• Microcomputer control system

• DC brushless motor for low-noise operation

• Storage for up to 9 user programs

• Electronic lid lock for added operational safety

• Automatic imbalance and over-temperature detection with alarms

• 9 acceleration levels and 10 deceleration levels

• Adjustable running time from 1 second to 99 minutes and 59 seconds

• Multiple rotor options for different tube capacities

• Compact tabletop design

Technical Specifications:

• Model: TD4

• Maximum speed: 4,000 rpm

• Maximum RCF: 2,500 × g

• Maximum capacity: 6 × 50 ml

• Speed accuracy: ±30 rpm

• Noise level: ≤60 dB(A)

• Power supply: AC 110 V or AC 220 V, 50/60 Hz

• Power consumption: 150 W

• Dimensions: 330 × 420 × 280 mm

• Net weight without rotor: 14 kg

Optional rotors are available for different tube sizes and capacities, including 10 ml, 15 ml and 20 ml configurations, depending on the rotor selected.

Contact FastonMed to enquire about the TD4 tabletop centrifuge, available rotor configurations and supply options in the UAE.
