HBO-07 Automatic External Defibrillator (AED) with Color LCD Display

The HBO-07 Automatic External Defibrillator (AED) is designed to support emergency response during sudden cardiac arrest. It features automatic ECG analysis, a biphasic waveform, and clear voice prompts to guide users through the defibrillation process.

The device supports both adult and pediatric modes, with selectable energy levels for different patient needs. Its color LCD, LED indicators, and five adjustable volume levels help communicate device status and instructions. The HBO-07 also includes daily and monthly self-tests to check its operational readiness.

With an IP55-rated enclosure, disposable adult and pediatric electrode pads, and voice prompts available in up to 12 languages, the HBO-07 is intended for use in locations such as hospitals, clinics, ambulances, offices, schools, hotels, sports facilities, and other public areas.

Key Specifications

• Model: HBO-07

• Device type: Automatic External Defibrillator (AED)

• Waveform: Biphasic

• Adult energy levels: 150 J / 200 J

• Pediatric energy levels: 50 J / 75 J

• ECG analysis time: 9 seconds

• Charging time: Less than 7 seconds to reach 150 J, as specified

• Voice guidance: Up to 12 languages

• Volume settings: 5 levels

• Self-test: Daily and monthly

• Patient impedance range: 20–2000 Ω

• Protection rating: IP55

• Display: Color LCD with LED indicators

• Electrode pads: Disposable adult and pediatric pads

The HBO-07 should be used by appropriately trained personnel and in accordance with the manufacturer's instructions and local emergency protocols.
